Article-No.:
92964
LED Downlight
Smart Home Zigbee 3.0
Nova Plus Swivelling
round 84mm 50° Coin 5,2W 400lm 230V dimmable RGBW+ Brushed iron
round 84mm 50° Coin 5,2W 400lm 230V dimmable RGBW+ Brushed iron
£55.95*
Prices incl. Standard rate VAT
Ready to ship, delivery within 2-3 working days
- Usable with smart home gateways that have a Zigbee interface
- Can be controlled with the Smart Home Zigbee remote control
- Can still be switched on and off with the light switch
LED Downlight Smart Home Zigbee 3.0 Nova Plus Coin Swivelling round 84mm 50° Coin 5,2W 400lm 230V dimmable RGBW+ Brushed iron
The Nova Plus coin RGBW recessed spotlight with colour-change function creates an individual atmosphere in your home. Depending on your mood, you can choose between daylight white, coloured light and various effects. A diode in white (W) additionally provides a cosy warm white light and makes it unnecessary to mix a white tone from the colours red, green and blue (RGB). The light is Zigbee 3.0-compatible. Zigbee 3.0 is a radio transmission protocol that links up the devices of several manufacturers. This allows not only the centralised control of lighting; shutters, heating and alarm systems, for example, can also be integrated. To operate the control, you can choose between the Smart Friends Box, a gateway for the same standard by a different manufacturer, or a Smart Home Zigbee 3.0 hand-held transmitter. Individual components can be addressed, or switched on and off in groups as lighting scenarios.
- Usable with smart home gateways that have a Zigbee interface
- Can be controlled with the Smart Home Zigbee remote control
- Can still be switched on and off with the light switch
- Bidirectional data transfer
- For 230 V direct connection
- RGBW multicolour colour change
- Color temperatur: 2700K - Warm white - 6500K -Daylight white
| Dimension | |
|---|---|
| Diameter | 84 mm |
| Built-in diameter | 68 mm |
| Mounting depth | 45 mm |
| Depth of hollow wall | 30 mm |
| net weight | 243 g |
| Design and Material | |
|---|---|
| Form | round |
| Light source shape | Coin |
| Colour | Brushed iron |
| Material | Aluminium |
| Stainless | stainless alu |
| Installation | |
|---|---|
| Installation site (recommendation) | Ceiling mounting |
| Energy consumption | |
|---|---|
| Energy efficiency (spectrum A-G) (LED Module) | G |
| Energy consumption | 7 kWh_1000h |
| Service life | |
|---|---|
| Lifetime | 30000 h |
| Light Characteristics | |
|---|---|
| Nominal luminous flux | 400 lm |
| Colour change | coloured light with Tunable White function (RGBW), Tunable White |
| Color rendering index | > 80 Ra |
| Beam angle | 100 ° |
| Colour temperature to | 6500 K |
| Colour temperature | Warm white to Daylight white, 2700 K |
| Colour consistency (SDCM) | 6 |
| Lamp Features | |
|---|---|
| Dimming Control | with Smart Home |
| Inclusive lamp | yes |
| Component parts | 5,2 W |
| light source property | Without light source |
| Swivel range | 50 ° |
| Incandescent Equivalent | 35 W |
| Compatible Smart Home technology | Zigbee |
| Base/Socket | Coin |
| Technique | LED |
| Adjustability | fixed |
| Dimmable | Yes |
| IP protection | IP23 ceiling mounting |
| Protection class | Protection class II |
| Number of component parts | 1x |
| Replacable | 2 Lightsource is replaceable without damage the lighting fixture by electrician. |
| Voltage | 230 V |
| Voltage type | AC 50 Hz |
| Transformer | |
|---|---|
| apparent power | 6.7 VA |
| Accessories | |
|---|---|
| Radio control included | no |
| Labelling | |
|---|---|
| MM symbol | MM symbol |
| WEEE-Reg.-No | DE 39236390 |
| Smart Home | |
|---|---|
| Protocol type | Zigbee 3.0 |
| Zigbee certification | Zigbee_certified |
| Radio frequency | 2,4 GHz |
| Radio range (Open field) | 20 m |
| Compatible smart home systems | Amazon Echo Smart Speaker with Zigbee 3.0 interface|Philips Hue Bridge 2 and Pro (excluded Hue Entertainment) |
