Article-No.:
99812
LED Recessed furniture luminaire
Micro Line 3-piece set
round 66mm 3x1W 3x34lm 230/12V 2700K Brushed iron
round 66mm 3x1W 3x34lm 230/12V 2700K Brushed iron
- Set of 3 lamps including LED, 3x1W
- Material: Metal
- Color: Brushed iron
LED Recessed furniture luminaire Micro Line 3-piece set round 66mm 3x1W 3x34lm 230/12V 2700K Brushed iron
The right choice for display cabinets, furniture, etc.: The Micro Line Flat LED furniture recessed luminaire set emits practically no heat at all and provides cupboard illumination for unobtrusive lighting and decorative effects.
- Set of 3 lamps including LED, 3x1W
- Material: Metal
- Color: Brushed iron
- Energy-saving LED technology (conserves up to 80% energy in comparison to conventional light bulbs)
- Low mounting depth: only 5mm
- Diameter: 65mm
- Operating voltage: 230/12 V
- protection class II
- Color temperatur: 2700K - Warm white
- Incl. plug-in connector and transformer
| Dimension | |
|---|---|
| Total Mounting depth | 5 mm |
| Dimensions (Height x Width x Depth) | H: 22 mm |
| Ø | 66 mm |
| Mounting hole | 54 mm |
| Form | round |
| Depth of hollow wall | 5 mm, 5 mm |
| Design and Material | |
|---|---|
| Colour | Brushed iron |
| Material | Metal |
| Installation | |
|---|---|
| Installation site (recommendation) | Installation on cabinet |
| Connections | |
|---|---|
| Plug-and-socket connector | Plug-and-socket connector |
| Energy consumption | |
|---|---|
| Energy efficiency (A to G) | F |
| Service life | |
|---|---|
| Lifetime | 20.000 h |
| Rated life time | 20000 h |
| Light Characteristics | |
|---|---|
| Colour temp. | 2700 K |
| Usable luminous flux | 34 lm |
| color temp | 2.700 K |
| Rated luminous flux (Lumen) | 34 lm |
| Lamp Features | |
|---|---|
| Component parts | 1 W |
| Technique | LED |
| IP protection | IP20 |
| Dimmable | No |
| Number of component parts | 3x |
| protection class | protection class II |
| Replacable | 3 Lightsource is not replaceable, the complete lighting must be replaced.|5 Control gear is replaceable without damage the lighting fixture by electrician. |
| Power consumption | 3,5 W |
| Transformer | |
|---|---|
| Transformer power | 3,6 VA |
| Transformer height | 19 mm |
| Transformer width | 39 mm |
| Transformer depth | 80 mm |
| Labelling | |
|---|---|
| MM symbol | MM symbol |
| WEEE-Reg.-No | DE 39236390 |
