Article-No.:
97725
VDE
Electronic transformer
Profi
max. 100-250W 230/12V 250VA Grey/Black
max. 100-250W 230/12V 250VA Grey/Black
- VDE certificated
- protection class II
- Dimmable with universal dimmer for all transformers (R,L,C)
VDE Electronic transformer Profi max. 100-250W 230/12V 250VA Grey/Black
This high-quality product lives up to its name. The transformer for the most sophisticated needs.
- VDE certificated
- protection class II
- Dimmable with universal dimmer for all transformers (R,L,C)
- Integrated fire protection
- Temperature monitor and electronic fuse
- Doubled primary connection for several transformers in a single switch
- Several secondary terminal pairs
- Max. 50° ambient temperature
- Middle outlet
| Dimension | |
|---|---|
| Dimensions (Height x Width x Depth) | H: 44 x B: 51 x T: 222 mm |
| Mounting hole | 64 mm |
| Design and Material | |
|---|---|
| Colour | Black, Grey |
| Material | Plastic |
| Features | |
|---|---|
| Softstart | Softstart |
| Integrated thermal protection | integrated thermal protection |
| Integrated temperature monitor and electronic fuse | Integrated temperature monitor and electronic fuse |
| Service life | |
|---|---|
| Service life, electronic ballast | 50000 h |
| Lamp Features | |
|---|---|
| Technique | Accessories without bulbs |
| Dimmable | with dimmer R, L, C (universal compatibility) |
| Inclusive lamp | no |
| Total Width | 51 mm |
| Maximum wattage range | max. 100-250 W |
| protection class | protection class II |
| Replacable | 7 not concerned. |
| Transformer | |
|---|---|
| Transformer power | 250 VA |
| Integrated fire protection | Integrated fire protection |
| elevated spike protection | elevated spike protection |
| Integrated spark protection | Integrated spark protection |
| integrated overload protection | integrated overload protection |
| Labelling | |
|---|---|
| VDE | VDE certificated |
| MM symbol | MM symbol |
| WEEE-Reg.-No | DE 39236390 |
