Article-No.:
79779
LED Pendant luminaire
Smart Home Zigbee 3.0
Puric Pane
2700K 1200lm / 700lm 11 / 7W Black/Grey dimmable
2700K 1200lm / 700lm 11 / 7W Black/Grey dimmable
- Dimmable
- swivelling
- Pendant length individually adjustable
LED Pendant luminaire Smart Home Zigbee 3.0 Puric Pane 2700K 1200lm / 700lm 11 / 7W Black/Grey dimmable
The smart Puric Pane pendant luminaire in black, grey with a diameter of 400mm creates captivating lighting effects with its simple, scaled-back design. The technical design luminaire features modern technology. Featuring both direct and indirect light, the pendant creates optimal lighting. The luminaire is Zigbee 3.0-compatible. Zigbee 3.0 is a radio transmission protocol that interlinks devices from different manufacturers.
- Dimmable
- swivelling
- Pendant length individually adjustable
- LED lamp (fixed) included in scope of delivery
- Controllable with Paulmann Zigbee remote control Gent 500.67
- Usable with smart home gateways that have a Zigbee interface
| Dimension | |
|---|---|
| Canopy depth | 35 mm |
| Ø | 400 mm |
| Pendulum length range | 30-150 cm |
| Design and Material | |
|---|---|
| Colour | Black, Grey |
| Material | Metal, Plastic |
| Installation | |
|---|---|
| can be used with the following dimmers | Paulmann SmartHome Zigbee Gent2 501.40 |
| Energy consumption | |
|---|---|
| Energy efficiency (A to G) | F |
| Service life | |
|---|---|
| Lifetime | 30000 h |
| Light Characteristics | |
|---|---|
| Colour temp. | 2700 K |
| Usable luminous flux | 1600 lm |
| Luminous flux LED module | 1900 lm |
| color temp | 2700 K |
| Lamp Features | |
|---|---|
| Component parts | 11 W |
| Compatible Smart Home technology | Zigbee |
| Technique | LED |
| IP protection | IP20 |
| Dim | with Smart Home |
| Dimmable | Yes |
| Inclusive lamp | yes |
| Incandescent Equivalent | 120 W |
| Number of component parts | 1x |
| protection class | protection class II |
| Replacable | 7 not concerned. |
| Power consumption | 25 W |
| Transformer | |
|---|---|
| apparent power | 27 VA |
| Transformer height | 22 mm |
| Transformer width | 43 mm |
| Transformer depth | 126 mm |
| Labelling | |
|---|---|
| WEEE-Reg.-No | DE 39236390 |
| Smart Home | |
|---|---|
| Protocol type | Zigbee 3.0 |
| Zigbee certification | Zigbee zertifiziert |
| Radio frequency | 2,4 GHz |
| Radio range (Open field) | 20 m |
