Article-No.:
93917
Plug & Shine
LED Surface-mounted floor luminaire
Warm white Individual Spot Double light emission, 180°
IP67 3000K 2x3,3W Anthracite
IP67 3000K 2x3,3W Anthracite
- IP Protection: IP67 - protected against temporary immersion
- 24 V surface-mounted luminaire
- Glare-free light, directed to the side
Plug & Shine LED Surface-mounted floor luminaire Warm white Individual Spot Double light emission, 180° IP67 3000K 2x3,3W Anthracite
Plug & Shine surface-mounted luminaires, made of weather-resistant pressure-cast aluminium, illuminate your paths and driveways without glare, so you can easily find your way after dark. The beam angle is 180 degrees. With transformers, connectors and additional luminaires from the Plug & Shine series, you can compile an individual lighting installation for your outdoor spaces.
- IP Protection: IP67 - protected against temporary immersion
- 24 V surface-mounted luminaire
- Glare-free light, directed to the side
- LED lamp (fixed) included in scope of delivery
- Color temperatur: 3000K - Warm white
- Compatible with all accessories in the Plug & Shine series
- Don't forget: Order compatible transformers as well!
- Remember: Order the cable at the same time!
- Can be switched and dimmed via the plug & shine controller (Accessories) using the remote control.
| Dimension | |
|---|---|
| Dimensions (Height x Width x Depth) | H: 155 mm |
| Ø | 193 mm |
| Form | round |
| Design and Material | |
|---|---|
| Colour | Anthracite |
| Material | Die cast aluminium |
| Installation | |
|---|---|
| can be used with the following dimmers | Paulmann Plug & Shine 180.10/ 180.11 |
| Application | For glare-free illumination of paths and driveways |
| Installation site (recommendation) | Floor mounting |
| Energy consumption | |
|---|---|
| Energy efficiency (A to G) | F |
| Service life | |
|---|---|
| Lifetime | 30000 h |
| Light Characteristics | |
|---|---|
| Colour temp. | 3000 K |
| Beam angle | 180 ° |
| Usable luminous flux | 120 lm |
| Luminous flux LED module | 330 lm |
| color temp | 3000 K |
| Color rendering index | > 80 Ra |
| Beam angle LED module | 116 ° |
| Lamp Features | |
|---|---|
| Component parts | 3,3 W |
| Technique | LED |
| IP protection | IP67 |
| Dim | with dimmer |
| Dimmable | Yes |
| Inclusive lamp | yes |
| Incandescent Equivalent | 53 W |
| Number of component parts | 2x |
| protection class | protection class III |
| Replacable | 3 Lightsource is not replaceable, the complete lighting must be replaced. |
| Power consumption | 6 W |
| Transformer | |
|---|---|
| apparent power | 6.7 VA |
| Labelling | |
|---|---|
| WEEE-Reg.-No | DE 39236390 |
